6 Axle 40m3 Dump Semi Trailer For Ghana

6 Axle 40m3 Dump Semi Trailer For Ghana

Product Details:

Place of Origin: CHINA
Brand Name: TRUCKMAN AUTO
Certification: SGS, BV, CIQ, FORM E
Model Number: TKM400DLT

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit
Price: negotiable
Packaging Details: Nude
Delivery Time: 20 working days
Payment Terms: L/C, T/T
Supply Ability: 1500 Unit / Per Month
Get Best Price Contact Now

Detail Information

Loading Tons: 80000 Kg Axle: 6x16000kg, 6 Axle
Support Leg: JOST, 28 Tons Suspension: Air And Mechanical Suspension
Tire: 385/80R22.5 And 315/80R22.5 Warranty: 1 Year
High Light:

40m3 Dump Semi Trailer

,

6 Axle Dump Semi Trailer

,

Dump Semi Trailer For Ghana

Product Description

6 Axle 40m3 Dump Semi Trailer For Ghana

-1. 40m3 Dump Trailer Detail.



6 axle 40m3 dump trailer special design for the Ghana, suitable for bauxite, manganese ore, limestone

etc haulage from mining site to loading port (Takoradi port). Also the axle suspension adopt the air and

mechanical type, meet the loading request and also can help reduce the fuel consumption



-. The whole 40m3 dump trailer bucket adopt the manganese plate Q345. This collocation can assured

the trailer meet the different road condition, and reduce the total cost.



-. The 40m3 dump trailer axle using FUWA brand 16 tons, total 6x16 tons. Can loading more than

80 tons cargoes



-2. 40m3 Dump Trailer Specification.



Description Parameter Value
Product Name 40m3 Dump Trailer
Application For transport bauxite, limestone, manganese etc
Main Frame Bottom 18mm, middle 8+8mm, upper 16mm
Axle 6 axle, 6x16000 tons, FUWA brand
Suspension Air and mechanical model, heavy duty
Support Leg 28 tons, JOST or FUWA brand
Brake System WABCO brand
Fifth Wheel 3.5 inch, for heavy duty loading
Tire 315/80R22.5, 16 pcs, LINGLONG brand
Rim 18mm thickness, for heavy loading
Bucket 11500x2300x1500mm, 40m3
Loading Tons 80 tons
Dimension 12500x2500x3450mm



6 Axle 40m3 Dump Semi Trailer For Ghana 0



The 40m3 dump trailer specification only for your reference, we will recommend other model dump trailer

according to your request.



-3. 40m3 Dump Trailer Suspension Picture.



6 Axle 40m3 Dump Semi Trailer For Ghana 1





Our 40m3 dump trailer suspension is two model, air and mechanical suspension. When loading less

cargoes, like loading 30 tons can lifting the front 3 axle, to save the fuel. When over 70 tons can put

all axle down increase the dump trailer loading capacity.



6 Axle 40m3 Dump Semi Trailer For Ghana 2



Air suspension for dump trailer
