3 Axles Concrete Mixer Trailer 40 Cubic Truckman Brand With Tool Box
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | TRUCKMAN |
| Certification: | SGS, BV, CTN |
| Model Number: | TKM40CCT |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Units |
|---|---|
| Price: | Price is negotiable |
| Packaging Details: | Nude |
| Delivery Time: | 20 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1500 Units Per Month |
|
Detail Information |
|||
| Axles: | 3 Axles, FUWA Brand | Support Leg: | JOST Brand |
|---|---|---|---|
| Brake System: | WABCO Brand | Tire: | 12.00R20,315/80R22.5/13R22.5 |
| Color: | Optional | Other: | With Tool Box |
| High Light: | cement powder tanker trailer,cement tanker truck |
||
Product Description
3 Axles Concrete Mixer Trailer 40 Cubic Truckman Brand With Tool Box
-1. Main Specification For The Concrete Mixer Trailer.
-. With 4 cylinder diesel WEICHAI brand engine
-. 35-55 cubic tank box
-. Easy unloading cement
-. Use good brand spare parts, such as FUWA, LINGLONG, JOST etc
-. Tire model could optional, such as 315/80R22.5, 12.00R20, 13R22.5
| Weight: | Loading Capacity | 60T |
| Axle Weight Load | 13T | |
| Specification | Axle number | 3 |
| Axle Brand | FUWA | |
| Suspension | Common mechanical | |
| King Pin | 2" or 3.5" traction pin | |
| Dimensions (LxWxH) | 13000*2500*4200mm | |
| Support legs | 28T | |
| Wheel Rim | 9.0-22.5 | |
| Wheelbase | 7180+1310+1310mm | |
| Steel Spring | 10 pieces per axle | |
| Tank body & end | St-37/4mm steel&6mm steel sheet Shape:V type | |
| Engine | Diesel engine:weichai brand model:4102.44 KW | |
| Discharge valve & pipe | 4” disc valve&4” seamless steel tube | |
| Air-charging system | 2” main hole. 2” check valve.1.5” safe valve.0.4Mpa.gauge | |
| Quadratic blow | 1” diameter check valve | |
| Discharge cover | 2-4 sets of 100mm discharge valves | |
| Landing Gear | Manual operating, Heavy duty landing gear (Brand Optional) | |
| Manhole cover | 500mm manhole cover 2 sets with 2 breather valve | |
| Accessories | 1 Set standard tool box | |
| Light | Tail lamp with turn signal, brake light & reflector, side lamp etc. | |
| Painting | 1coat of anti corrosive primer, twice coats of final paint | |
| compressor | BOHAI brand 14M3 | |
| Tire: | Tire spe. | 12R22.5 Chinese brand |
| Number of Tire | 12 pieces | |
| Spare Tire Carriers | 2 pieces | |
| Frame: (specs. and materials) | Main beam | The height of the beam is 500mm; |
| Down plate is 16mm;Middle plate is 8mm. Up plate is 14mm | ||
| Tank body | 5mm steel plate, head and back head made of 6mm steel plate | |
| the shape can be column or TV square shape | ||
| Brake | Brake Chamber | Six big chamber( Brand Optional ) |
| Brake system | Dual Line Brake system (ABS ) |
-2. Shipment Details.
There have RO-RO, BULK CARGO, FRAME vessel could choose, and delivery time could guarantee.
And with different freight cost, please contact with us get more details.
