3 Axle 26000 Liter Oil Tank Semi Trailer With Compartment
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | TRUCKMAN AUTO |
| Certification: | SGS, BV, CIQ, FORM E |
| Model Number: | TKM260FTL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Unit |
|---|---|
| Price: | negotiable |
| Packaging Details: | Nude |
| Delivery Time: | 20 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1500 Unit / Per Month |
|
Detail Information |
|||
| Loading Tons: | 26000 Liter, 8 Compartment | Axle: | 3x16000kg, 3 Axle |
|---|---|---|---|
| Tire: | 12R22.5, 12 Pcs Tire | Suspension: | 8mm Heavy Duty Model |
| Tractor Pin: | 90#, 3.5 Inch | Support Leg: | 28 Tons, JOST Brand |
| High Light: | 26000 Liter Oil Tank Semi Trailer,Liquid Transport Oil Tank Semi Trailer,3 Axle Oil Tank Semi Trailer |
||
Product Description
3 Axle 26000 Liter Oil Tank Semi Trailer With Compartment
3 Axle 26000 Liter Oil Tank Semi Trailer With Compartment
-1. 3 Axle Oil Tank Semi Trailer Detail.
3 axle oil tank semi trailer loading tons from 20,000 liter to 50,000 liter, material can use the
aluminum alloy, stainless steel and carbon steel.
-. Adopt the heavy duty suspension design, suitable for bad road work condition.
-. Every compartment with the separate sub valve.
-2. 3 Axle Oil Tank Semi Trailer Specification.
| Description | Parameter Value |
| Product Name | 3 Axle Oil Tank Semi Trailer |
| Application | For liquid transport |
| Axle | 3 axle, 16 tons axle |
| Suspension | Heavy duty 8mm thickness |
| Leaf Spring | 90x16mmx10pcsx6sets |
| Tire | 12R22.5, 12 pcs, tubeless model |
| Rim | 16mm thickness |
| Support Leg | JOST brand, 28 tons |
| Tractor Pin | JOST brand, 90# heavy duty version |
| Tank Body | 8 compartment, total 26000 liter |
| Dimension | 12500x2500x3650mm |
The 3 axle oil tank semi trailer specification only for your reference, we will recommend other
model oil tank semi trailer according to your request.
-3. 3 Axle Oil Tank Semi Trailer Subsea Valve Detail.
oil tank semi trailer subsea valve also called emergency shut-off valve, is a safety valve
installed at the loading and unloading port of metal atmospheric tank of liquid dangerous
goods tank vehicle.
Although the subsea valve is only an inconspicuous part on the vehicle body, it plays a
vital role. It can not only effectively absorb the energy transmitted by the vehicle
damaged by the impact of the pipeline, but also ensure the integrity of the sealing
mechanism to avoid Material leakage greatly improves the security in ensuring the
safety of the entire vehicle and avoiding dangerous accidents.
