25000 Liters 25 Tons Full Trailer Truck High Loading With The Drawbar Big
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | TRUCKMAN AUTO |
| Certification: | SGS, BV |
| Model Number: | TKM25OFL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Unit |
|---|---|
| Price: | Price is negotiable |
| Packaging Details: | Nude |
| Delivery Time: | 20-25 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1500 Unit / Per Month |
|
Detail Information |
|||
| Tank Body: | 25m3 | Loading Tons: | 25 Tons |
|---|---|---|---|
| Axles: | 3x13 Tons, FUWA, BPW | Brake: | ABS, 4M/4S |
| Tire: | 12.00R20, 315/80R22.5 | Others: | With Fire Extinguisher |
| High Light: | full trailer,draw bar trailer |
||
Product Description
25000 Liters 25 Tons Full Trailer Truck High Loading With The Drawbar Big
25000 Liters 25 Tons Oil Tank Full Trailer Truck With The Drawbar Big
. Main Specification For The Full Tanker Trailer.
-. With the drawbar connect with the fuel tank trucks.
-. Loading 25 tons with the stronger chassis.
-. All FUWA, LINGLONG etc famous brand spare parts.
-. The main material is Q345B, high strength steel.
| Tare Weight | About 7.6T | ||
| Outer Side Dimension | 7800mm*2500mm*3600mm | ||
| Loading Capacity | 50T | ||
| Total Volume | 25m³-60 m³ | ||
| Tanker body material | 5mm or 6mm Q235 carbon steel /aluminum /stainless steel | ||
| End Plate | 5mm or 6mm Q235 carbon steel /aluminum /stainless steel | ||
| Manhole Cover | Cabon steel or Aluminum alloy API manhole cover, ∮500mm | ||
| Bottom Valve | Aluminum API Pneumatic Bottom Valve | ||
| Discharging Valve | Diameter is 3 or 4 inch | ||
| Compartments | Optional | ||
| Discharging Pipe | 4” rubber hose, 2 pcs, 6m/each | ||
| Cat Walk | With (Common model or special design) | ||
| Chassis parts | |||
| Main Beams | Weldding design or Special design I beam, connected by bolts and nuts Q345 carbon steel material | ||
| Axle | 2 or 3 axles, BPW/FUWA/HUAJING brand | ||
| Landing Gear | JOST (D200T)or CHINA BRAND 28T | ||
| King Pin | JOST 2.00 or 3.5 inch bolt-in king pin | ||
| Suspension | Mechanical suspension/Germany or America type /air suspension | ||
| Leaf Spring | 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12 /without | ||
| Pneumatic Braking System | WABCO RE 6 relay valve; Spring brake chamber(TKL brand); one piece of 45L air tanks. | ||
| Rim | 9.00-22.5/8.00-20/8.5-20 China Brand | ||
| Tire | 12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand can be Optional | ||
| ABS | Optional | ||
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint | ||
| Accessories | One standard tool box | ||
-2. FAQ
-. Terms of paymemt.
30% as the deposit by T/T, 70% balance before delivery.
-. What’s your MOQ?
One unit trailer or truck. But suggest two trailers one time to save the freight.
-. Whats your delivery time.
20-25 working days after received the deposit.
-. What is your terms of shipment?
The trailer could arrange shipment by ro-ro ship, bulk cargo vessel, container etc.
-. Can you accept the custom made?
Definitely! We could design the trailer according to your request.
-. What’s your warranty?
All of our trailers meet the CIQ, SGS, BV, ADR, FORM E quality certificate, and we will supply one year warranty for the trailers.
